Trimble TX8 Battery Replacement

Battery Specifications for Trimble TX8 Battery

• Model: Ni2020TM29
• Type: Li-Ion
• Voltage: 10.8V
• Capacity: 8.7Ah
• Energy: 94Wh
• Charger: 12.6V

Replacement Steps for Trimble TX8 Battery

1. Prepare the Equipment

Ensure the scanner is powered off and gather necessary tools along with a new battery for the Trimble TX8. This battery is essential for maintaining the performance of your Trimble TX8 3D laser scanner.

2. Access the Battery Compartment

Locate and open the battery compartment of your Trimble TX8 3D laser scanner.

3. Remove the Old Battery

Disconnect and take out the old battery. Remember, this process is similar for other models in the Trimble TX series, including the TX5 and TX6.

4. Insert the New Battery

Connect the new battery securely into the compartment. Ensure you are using a compatible battery, such as the NI2020TM29 Li-Ion battery.

5. Close the Battery Compartment

Ensure the battery compartment is properly secured after installation to protect your 3D laser scanner Trimble TX8.

6. Power On the Scanner

Check if the scanner recognizes the new Trimble TX8 battery. A properly installed battery is crucial for optimal performance.

Warnings for Trimble TX8 Battery

• • Charge only with a sumbus compliant level 2 or 3 charger.
  • Do not heat above 20°C.
  • Do not open the battery, dispose of in fire, or short circuit.
  • May ignite, explode, leak, or get hot causing personal injury.
  • Replace battery with the same part number only; use of another battery may present a risk of fire or explosion.
  • Keep away from children.
